THUNDERBOLT™ 3 & USB INTERFACE WITH
12 DISCRETE PREAMPS AND 6DSP + 2FPGA FX PROCESSORS

Features

  • 6x DSP + 2x FPGA Synergy Core FX Processing
  • Thunderbolt™ 3 & USB 2.0 Connectivity
  • 12 discrete mic preamps with mic/line/instrument/direct recording
  • State-of-the-art AD/DA converters
  • 64-bit Acoustically Focused Clocking with oven-controlled crystal oscillator
  • 2 mastering-grade Stereo monitor outputs
  • 2 individual Stereo headphone outputs
  • 2 Insert inputs and 2 ReAmp outputs
  • 2x ADAT, S/PDIF, Word Clock digital I/O
  • 16 line outputs on DB25 connectors
  • Integrated Talkback microphone
  • Intuitive software Control Panel with flexible signal routing

Specifications

ANALOG

Analog Inputs
8 x Mic / Line Inputs / Direct In
4 x Mic / Line / Hi-Z Inputs / Direct In

Analog Outputs
2 x Monitor Out on TRS 1/4 Jacks: Can work Together
2 x ReAmp Out on TRS 1/4 Jacks
2 x Line Out (16 channels) on DB25, +20 dBu max, impedance balanced
2 x Stereo Headphone Outputs

Mic Preamp
EIN: -128 dBu
Dynamic Range: -121 dB
THD: -106 dB
Max input: +20 dBu
Max Gain: 75 dB

D/A Monitor Converter
Dynamic Range: 130 dB
THD + N: -115 dB

A/D Converter
Dynamic Range: 124 dB
THD + N: -112 dB

D/A Converter
Dynamic Range: 128dB
TTHD + N: -115dB

DIGITAL

Digital Inputs
2 x ADAT (up to 16CH)
1 x S/PDIF on RCA

Digital Outputs
2 x ADAT (up to 16CH)
1 x S/PDIF on RCA

USB 2.0 I/O
USB 2.0 Type B connector
(up to 24 channels)

Thunderbolt™
Thunderbolt™ 3 connector
(up to 32 channels)

CLOCKING

Word Clock Input
1 × Input @ 75 Ohms 3Vpp
on BNC 32 – 192kHz

Word Clock Outputs
1 × Outputs @ 75 Ohms 3Vpp
on BNC 32 – 192kHz

Clocking System
4th Generation Acoustically
Focused Clocking
64-bit DDS

Sample Rates (kHz)
44.1, 48, 88.2, 96, 176.4, 192

OTHER

Operating Temperature
0-50°C, 32-122°F

Weight (Approx)
3.1 kg/ 6.83 lbs

Dimensions (Approx)
Width: 483 mm / 19”
Height: 44 mm / 1.7”
Depth: 220 mm /8.6”

Power Consumption
25 Watts

System Requirements

WINDOWS

PCComputer with Thunderbolt™ 3 and/or USB ports
OSWindows 10 x64 with the latest updates
RAM4GB minimum (8GB or more recommended)
CPUIntel Core i3™ or AMD FX and higher

MAC

ModelApple Mac 2012 or newer Thunderbolt™ 3 and/or USB ports
OS XmacOS 10.12 (Sierra) and higher - Recommended macOS 10.14 (Mojave)
Memory (RAM)4GB minimum (8GB or more recommended)
