Transform your studio recordings
with a single microphone
EDGE DUO
capsule
- Capsule: Single Capsule
- Diaphragm: Large – double-sided 6u gold-sputtered membranes
- Diaphragm diameter: 34mm
- Polar Pattern: Multi-pattern (cardioid, figure-8, omnidirectional)
sound
- Freq. response: 20HZ ~ 20kHZ
- Self-noise: 19dB(A)
- SNR: 75dB(A)
- Sensitivity: -35dB | 18mV/Pa (-1 to +3dB)
- THD+N: -116dB
hardware
- Power Requirements: 48V DC phantom power
- Output impedance: 50 Ohms @ 1kHz
- Output Connector: 5-pin male XLR
- Output Channels: 2 separate XLR output channels
- Weight: (mic body): 1.23 lbs (560 grams)
- Dimensions (mic body): 8.6″ x 2.1″ (219mm x 53mm)
in the box
- Breakout Cable: 16.4′ (5 meters) 5-pin female XLR to dual
3-pin male XLR (high grade oxygen-free copper Y-cable) - Mount: Shock absorber
- Pop-filter: Included
