EDGE DUO

Transform your studio recordings
with a single microphone

capsule

  • Capsule: Single Capsule
  • Diaphragm: Large – double-sided 6u gold-sputtered membranes
  • Diaphragm diameter: 34mm
  • Polar Pattern: Multi-pattern (cardioid, figure-8, omnidirectional)

sound

  • Freq. response: 20HZ ~ 20kHZ
  • Self-noise: 19dB(A) S
  • NR: 75dB(A)
  • Sensitivity: -35dB | 18mV/Pa (-1 to +3dB)
  • THD+N: -116dB

hardware

  • Power Requirements: 48V DC phantom power
  • Output impedance: 50 Ohms @ 1kHz
  • Output Connector: 5-pin male XLR
  • Output Channels: 2 separate XLR output channels
  • Weight: (mic body): 1.23 lbs (560 grams)
  • Dimensions (mic body): 8.6″ x 2.1″ (219mm x 53mm)

in the box

  • Breakout Cable: 16.4′ (5 meters) 5-pin female XLR to dual
    3-pin male XLR (high grade oxygen-free copper Y-cable)
  • Mount: Shock absorber
  • Pop-filter: Included
