A NEW LEVEL OF IMMERSION

GALAXY 32 SYNERGY CORE

NOW ATMOS-READY

EMBRACE THE FUTURE OF AUDIO PRODUCTION

The Galaxy 32 Synergy Core now becomes the perfect interface for any surround or immersive audio setup. Ideal for studio use such as music mixing and mastering, film, TV, game and VR audio production, Galaxy 32 is also the optimum device for live use with multi-channel speaker array sound systems for venue and theatre PA, art installations and more.

Control panel Surround tab 2

ENHANCE YOUR IMMERSIVE SETUP WITH
EXTENSIVE FUNCTIONALITY

Take advantage of the interface’s limitless routing, as well all the immersive monitoring functionality to build your dream setup for any spatial audio application.

Control panel Surround tab

Comprehensive speaker
calibration capabilities

Flexible 8-band parametric equalizer, independent level adjustment and delay line, for speaker tuning and room correction.

Control panel Surround tab 1

Powerful monitoring controller
built in

Color-coded, speaker layout visual representation allows mute and solo functionality, with metering and output volume controls.

Bass management mixer

Flexible Bass management
mixer

Configurable crossover filters on each speaker channel allow for sending low-frequency information to the LFE channel instead, to help dial in that low end.

Routing

Broad compatibility
via limitless I/O routing

Hardly any setup configuration is left unaccounted for with full access to the interface’s Thunderbolt, Dante, MADI, HDX, ADAT, SPDIF or analog line-level audio connectivity.

©Valhalla Studios, New York

MONITORING FROM STEREO TO
9.1.6 DOLBY ATMOS, AND MORE

More than 23 format variations come preconfigured and ready to use, for a seamless setup process. If anything outside the provided formats and channel path orders is required, configurations up to the 16 channel limit are possible when utilizing the interface’s signal routing matrix. This opens the door to all of the aforementioned functionality when monitoring a wide range of channel-, object- and scene-based formats, such as DTS:X, Аmbisonics (up to 3rd order), Auro 3D among others.

SURROUND AND IMMERSIVE AUDIO MONITORING

Wide compatibility, both setup and format wise

  • Any combination of the interface’s Dante, MADI, HDX, ADAT, SPDIF and analog I/O is available
  • 23 preconfigured formats with path order selection (SMPTE / film), including 2.1, 5.1, 7.1 surround sound and 5.1.2, 7.1.4, 9.1.6 Dolby Atmos
  • Additional audio formats and speaker configurations possible via the built-in routing, up to the 16-channel limit

Monitor controller functionality for improved mixing workflow

  • Color-coded speaker selection with mute, solo and metering functionality
  • Main speaker volume level available via front panel encoder.

All 16 available monitoring channels support the following:

  • 8-band parametric EQ
  • Level trim from –60dB to +16dB
  • Up to 100ms delay for calibration purposes
  • Phase invert
  • Global “lip-sync” delay up to 100ms
  • Bass management functionality with flexible crossover filters and dedicated mixer window
